Assumed:
- Distance covered = 2000 mm
- Measuring system actual position after 2000 mm = 607682 steps
Derived:
Number of revolutions covered = 607682 steps / 4096 steps/rev.
= 148.3598633 revolutions
Number of mm / revolution = 2000 mm / 148.3598633 revs. =
13.48073499mm / rev.
For 1/100mm resolution this equates to a
Measuring units per revolution
of
1348.073499
Required programming:
Number of Revolutions Numerator = 4096
Number of Revolutions Denominator = 1
Total Number of Steps = Measuring units per revolution *
Number of Revolutions Numerator
Number of Revolutions Denominator
= 1348,073499 steps / rev. *
4096 Revolutions Numerator
1 Revolutions Denominator
=
5521709 steps
(rounded off)
