7.3.5 Auxiliary Outputs 1 - 7
Function
Description
Programming value
logical "0"
Output is always "0"
0
0 = error
Output in the case of an error "0"
1
1 = error
Output in the case of an error "1"
2
0 = below the operating range
see chap. "7.3.5.1", page 64
3
1 = below the operating range
"
4
0 = in the operating range
"
5
1 = in the operating range
"
6
0 = above the operating range
"
7
1 = above the operating range
"
8
0 = below the safety range
"
9
1 = below the safety range
"
10
0 = in the safety range
"
11
1 = in the safety range
"
12
0 = above the safety range
"
13
1 = above the safety range
"
14
Auxiliary Output 1 - 7
Instance
10 – 16, r/w
lower limit
0
upper limit
14
default
0
