Installation / Preparation for start-up
TR-Electronic GmbH 2007, All Rights Reserved Printed in the Federal Republic of Germany
Page 48 of 68 TR - ECE - BA - DGB - 0065 - 03 03/11/2016
5.1 Connection
The connection hood must first be removed from the measuring system to undertake
connection.
The pin assignments with view on the switches etc. are attached in the rear part of this
document.
For the supply shielded cables with twisted core pairs and min. 0.5 mm
2
have
to be used !
5.2 Bus termination
If the measuring system is the last slave in the CAN segment, the bus is to be
terminated with the termination switch = ON. In this state, the subsequent CAN-bus is
decoupled.
5.3 Identifier (MAC-ID)
The identifier (measuring system address) 0 – 63 is adjusted via 6 DIP-switches. The
adjusted address may be assigned only once in the CAN bus.
5.4 Baud rate
The baud rate is adjusted via 2 DIP-switches.
Following baud rates are possible:
● 125 kBaud
● 250 kBaud
● 500 kBaud
