7 Parameterization and configuration
Danger of personal injury and damage to property exists if the measuring
system is restarted after positioning in the de-energized state by shifting
of the zero point!
If the number of revolutions is not an exponent of 2 or is >4096, it can occur, if
more than 512 revolutions are made in the de-energized state, that the zero
point of the multi-turn measuring system is lost!
 Ensure that the quotient of Revolutions Numerator / Revolutions
Denominator for a multi-turn measuring system is an exponent of 2 of the
group
2
0
, 2
1
, 2
2
…2
12
(1, 2, 4…4096).
or
 Ensure that every positioning in the de-energized state for a multi-turn
measuring system is within 512 revolutions.
7.1 Configuration Assembly Data Attribute Format
7.1.1 Assembly Object 04h
Instance
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Service
42
0
Direction
r/w
1
Output Code
2
Low Byte Total Number of Steps
to
5
High Byte Total Number of Steps
6
Low Byte Revolutions Numerator
to
9
High Byte Revolutions Numerator
10
Revolutions Denominator
11
Low Byte Lower Safety Limit
to
14
High Byte Lower Safety Limit
15
Low Byte Lower Operating Limit
to
18
High Byte Lower Operating Limit
19
Low Byte Upper Operating Limit
to
22
High Byte Upper Operating Limit
23
Low Byte Upper Safety Limit
to
26
High Byte Upper Safety Limit

