Instance
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Service
42
27
Auxiliary Output 1
r/w
28
Auxiliary Output 2
29
Auxiliary Output 3
30
Auxiliary Output 4
31
Auxiliary Output 5
32
Auxiliary Output 6
33
Auxiliary Output 7
34
Low Byte Value for Preset1
to
37
High Byte Value for Preset1
38
Low Byte Value for Preset2
to
41
High Byte Value for Preset2
42
Preset 2
out of
range
0
0
0
0
0
Write-
error
Read-
error
43
0
Steps/Rev.
exceeded
3)
TNOS/Rev.
=0
upper
1)
SL
out of
range
upper
2)
OL
out of
range
lower
2)
OL
out of
range
lower
1)
SL
out of
range
Preset 1
out of
range
While programming the parameters via the "Assembly-Class" the measuring system returns as
response at reading the programmed values with an error status in byte 42 and 43 to the
master. In this case altogether 44 bytes are transferred to the master. The Data Check is
performed automatically.
A set error bit in byte 42 or 43 is reset as soon as a parameter programming could be executed
successfully. The ranges of values of the individual parameters are defined in chapter
"Parameters / Range of values" starting from page 58.
1)
SL = Safety Limit
2)
OL = Operating Limit
3)
TNOS = Total Number of Steps
