Commissioning
 TR-Electronic GmbH 2007, All Rights Reserved Printed in the Federal Republic of Germany
Page 54 of 68 TR - ECE - BA - DGB - 0065 - 03 03/11/2016
Output Instance
Number
Name
1
Preset / Direction (F/B)
Output Data Format
Instance
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
1
0
X
X
X
X
X
X
Preset 2
Preset 1
1
F/B
F/B
F/B
F/B
F/B
F/B
F/B
F/B
Risk of injury and damage to property by an actual value jump when the
Preset adjustment function is performed!
 The preset adjustment function should only be performed when the
measuring system is at rest, otherwise the resulting actual value jump must
be permitted in the program and application!
● Execute Preset
To adjust the measuring system to the internal stored preset value 1, bit 2
0
of the
out-byte 0 has to be set to "1".
To adjust the measuring system to the internal stored preset value 2, bit 2
1
of the
out-byte 0 has to be set to "1".
If the bits 2
0
and 2
1
are set to "1" at the same time, no preset is executed.
For a new preset-adjustment each of the bits has to be reset to "0" for at least one
polling cycle. Preset-cycles lower than 500ms are not allowed.
● Define counting direction, view onto the shaft of the measuring system
- Out-Byte 1: All bits = 1 --> decreasing position values, CW
- Out-Byte 1: All bits = 0 --> increasing position values, CW
The value for the counting direction, programmed by means of the Device-Net-
Manager, is overwritten by the transmitted bits in the Out-Byte 1.
