Installation
30 RT-SVX36K-EN
Table 9. SEHL, SFHL, SLHL, SSHL, SXHL units (20 - 89 ton)
Unit Size
Air-Cooled Unit Dimensions
A B C D E F G H J K L M N O
20 & 25 Ton 24'-1 3/8" 6’-9” 7'-6 1/2" 7’-3 1/4” 3'-9 5/16" 13'-3" 1" 7' 1'-3 1/2" 16'-7" 16'-6" 8 1/8" 6 1/4" 9"
30 Ton 24'-1 3/8" 6’-9” 7'-6 1/2" 7’-3 1/4” 4'-9 5/16" 13'-3" 1" 7' 1'-3 1/2" 16'-7" 16'-6" 8 1/8" 6 1/4" 9"
40 Ton 32'-10 1/2” 6’-9” 7'-6 1/2" 7’-3 1/4” 5'-9 5/16" 15'-11 1/8" 1" 8' 2'-5" 19'-7"
See
Note
8 1/8" 6 1/4" 9"
50 Ton 32'-10 1/2" 6’-9” 7'-6 1/2" 7’-3 1/4” 6'-9 5/16" 15'-11 1/8" 1" 8' 2'-5" 19'-7"
See
Note
8 1/8" 6 1/4" 9"
60 Ton 32'-10 1/2” 6’-9” 9'-8" 7’-3 1/4” 5'-9 5/16" 15'-11 1/8" 1" 8' 2'-5" 19'-7"
See
Note
8 1/8" 6 1/4" 9"
70 & 75 Ton 32'-10 1/2” 6’-9” 9'-8" 7’-3 1/4” 5'-9 5/16" 15'-11 1/8" 1" 8' 2'-5” 19'-7"
See
Note
8 1/8" 6 1/4" 9"
Table 10. SEHL, SFHL, SLHL, SSHL, SXHL units (20 - 89 ton)
Unit Size
Evaporative Condensing Unit Dimensions
A B C D E F G H J K L M N O
24 & 39 Ton 26’5 1/2” 6’-9” 7’-6 1/2” 8’-4 3/4” 3’-9 5/16” 13’-3” 1" 7” 1'-3 1/2" 16'-7" 16'-6" 8 1/8" 6 1/4" 9"
36 Ton 26’5 1/2” 6’-9” 7’-6 1/2” 8’-4 3/4” 4’-9 5/16” 13’-3” 1" 7” 1'-3 1/2" 16'-7" 16'-6" 8 1/8" 6 1/4" 9"
48 Ton 32’-10 1/2” 6’-9” 7’-6 1/2” 8’-4 3/4” 5’-9 5/16” 15’-11 1/8” 1" 8” 2'-5" 19'-7"
See
Note
8 1/8" 6 1/4" 9"
59 Ton 32’-10 1/2” 6’-9” 7’-6 1/2” 8’-4 3/4” 6’-9 5/16” 15’-11 1/8” 1" 8” 2'-5" 19'-7"
See
Note
8 1/8" 6 1/4" 9"
73 Ton 32’-10 1/2” 6’-9” 9’-8” 8’-4 3/4” 5’-9 5/16” 15’-11 1/8” 1" 8” 2'-5" 19'-7"
See
Note
8 1/8" 6 1/4" 9"
80 & 89 Ton 32’-10 1/2” 6’-9” 9’-8” 8’-4 3/4” 5’-9 5/16” 15’-11 1/8” 1" 8” 2'-5” 19'-7"
See
Note
8 1/8" 6 1/4" 9"
Note: 19'-6” for SFHL “High Heat” units or 20'-3” for SFHL “Low Heat” units.
Table 11. SEHL, SFHL, SLHL, SSHL, SXHL units (20 - 89 ton)
Unit Size
(AC/EC)
Dimensions
A B C D
E
F
G F
w/
exhaust
fan
w/
return fan
w/
exhaust
fan
w/
return
fan
w/
exhaust
fan
w/
return
fan
20-30
/24-36 Ton
16'-3 3/16" 2'-2 1/2" 5 13/16" 5'-7" 3'-4 3/8" 2'-9 15/16” 5 13/16" 6'-6 15/16" 3' 5 13/16" 28 5/8”
40 & 50
/48 & 59 Ton
19'-10 5/16" 2'-5" 7 1/16" 5'-7" 3'-4 3/8" 3'-1 1/2” 5 13/16" 7'-8 3/16" 3'-4” 5 13/16" 32 15/16”
60/73 Ton 19'-10 5/16" 2'-5" 6 1/16" Note 1 4'-5 3/8" 4'-2 1/2” 5 13/16" 7'-8 3/16" 4'-5” 5 13/16" 26 7/16”
70-75
/80-89 Ton
19'-10 5/16" 2'-5" 6 1/16" Note 1 4'-5 3/8" 4'-2 1/2” 5 13/16" 7'-8 3/16" 4'-5” 5 13/16" 26 7/16”
HJKL
20-30
/24-36 Ton
15'-5 5/16" 16'-9 3/4" 8 13/16" 9 1/16"
40 & 50
/48 & 59 Ton
18'-11 11/16" Note 2 8 3/16" 9 1/16"
60/73 Ton 18'-11 11/16" Note 2 8 3/16" 9 1/16"
70-75
/80-89 Ton
18'-11 11/16" Note 2 8 3/16" 9 1/16"
Notes:
1. 5'-5 15/16” for SEHL units or 7'-8 1/2” for SFHL, SLHL, SSHL, SXHL units.
2. 20'-1 3/4” for SFHL “High Heat” units or 20'-6 3/4” for SFHL “Low Heat” units. Either is selectable in field for SL and SS Return.

Trane IntelliPak Specifications

General

Refrigerant	R-410A
Compressor Type	Scroll
Voltage	208/230/460V, 3-phase
Type	Rooftop Unit
Airflow Configuration	Horizontal
Sound Level	Varies by model
Control System	Tracer
Dimensions	Varies with model
Weight	Varies with model
Heating Capacity	Optional electric or gas
