Trane IntelliPak User Manual

Installation
RT-SVX36K-EN 59
Table 22. Compressor electrical service sizing data (20-130 ton)
200V 230V 460V 575V
Tonnage
No. of
Compressors RLA LRA RLA LRA RLA LRA RLA LRA
20 Std 2 41.4 267.0 40.3 267.0 19.1 142.0 15.8 103.0
20 Hi Eff 2 41.4 267.0 40.3 267.0 19.1 142.0 15.8 103.0
25 Std
1 41.4 267.0 40.3 267.0 19.1 142.0 15.8 103.0
1 47.0 304.0 41.0 304.0 20.2 147.0 17.1 122.0
25 Hi Eff
1 41.4 267.0 40.3 267.0 19.1 142.0 15.8 103.0
1 51.9 315.0 47.0 315.0 22.2 158.0 19.2 136.0
30 Std 2 51.9 315.0 47.0 315.0 22.2 158.0 19.2 136.0
30 Hi Eff
1 51.9 315.0 47.0 315.0 22.2 158.0 19.2 136.0
1 56.9 351.0 48.8 351.0 25.5 197.0 23.1 135.0
40 Std
2 31.3 203.0 30.4 203.0 13.1 98.0 11.9 84.0
2 37.3 267.0 31.8 267.0 15.9 142.0 15.2 103.0
40 Hi Eff 4 37.3 267.0 31.8 267.0 15.9 142.0 15.2 103.0
40 Vari Spd
1
(a)
80.0 N/A 80.0 N/A 40.0 N/A 39.0 N/A
1 31.3 203.0 30.4 203.0 13.1 98.0 11.9 84.0
1 37.3 267.0 31.8 267.0 15.9 142.0 15.2 103.0
50 Std 4 41.4 267.0 40.3 267.0 19.1 142.0 15.8 103.0
50 Hi Cap & Hi Eff
2 41.4 267.0 40.3 267.0 19.1 142.0 15.8 103.0
2 47.0 304.0 42.3 304.0 20.2 147.0 17.1 122.0
50 Vari Spd
1(a) 104.0 N/A 104.0 N/A 55.0 N/A 49.0 N/A
1 41.4 267.0 40.3 267.0 19.1 142.0 15.8 103.0
1 47.0 304.0 42.3 304.0 20.2 147.0 17.1 122.0
55 Std & Hi Eff 4 47.0 304.0 42.3 304.0 20.2 147.0 17.1 122.0
55 Vari Spd
1(a) 104.0 N/A 104.0 N/A 55.0 N/A 49.0 N/A
1 47.0 304.0 42.3 304.0 20.2 147.0 17.1 122.0
1 51.9 315.0 47.0 315.0 22.2 158.0 19.2 136.0
60 Std
2 47.0 304.0 42.3 304.0 20.2 147.0 17.1 122.0
2 51.9 315.0 47.0 315.0 22.2 158.0 19.2 136.0
60 Hi Cap & Hi Eff 4 51.9 315.0 47.0 315.0 22.2 158.0 19.2 136.0
60 Vari Spd
1(a) 104.0 N/A 104.0 N/A 55.0 N/A 49.0 N/A
1 51.9 315.0 47.0 315.0 22.2 158.0 19.2 136.0
1 56.9 351.0 48.8 351.0 25.5 197.0 23.1 146.0
70 Std & Hi Eff 4 56.9 351.0 48.8 351.0 25.5 197.0 23.1 146.0
70 Vari Spd
1(a) 104.0 N/A 104.0 N/A 55.0 N/A 49.0 N/A
1 60.5 320.0 52.0 320.0 25.4 160.0 20.3 135.0
1 83.9 485.0 74.5 485.0 37.2 215.0 29.8 175.0
75 Std
2 60.5 320.0 52.0 320.0 25.4 160.0 20.3 135.0
2 83.9 485.0 74.5 485.0 37.2 215.0 29.8 175.0
75 Hi Cap & Hi Eff
2 60.5 320.0 52.0 320.0 25.4 160.0 20.3 135.0
2 83.9 485.0 74.5 485.0 37.2 215.0 29.8 175.0
90 Std & Hi Cap 4 N/A N/A N/A N/A 37.2 215.0 29.8 175.0
105 Hi Cap
2 N/A N/A N/A N/A 37.2 215.0 29.8 175.0
2 N/A N/A N/A N/A 45.0 260.0 36.0 210.0
115 Std
2 N/A N/A N/A N/A 37.2 215.0 29.8 175.0
2 N/A N/A N/A N/A 45.0 260.0 36.0 210.0
130 Std 4 N/A N/A N/A N/A 45.0 260.0 36.0 210.0
(a)Variable Speed Compressor
