Trane Jupiter JDAC Series User Manual

25
Installazione
Funzionamento
Manutenzione
Unità ad alta precisione Jupiter
Unità a espansione diretta
JDAC / JUAC / JDAV / JUAV / JDWC / JUWC / JDWV / JUWV
Taglie: 0115 – 0125 – 0133 – 0135 – 0150 – 0160
Unità ad acqua refrigerata
JDCC / JUCC / JDCV / JUCV
Taglie: 0020 – 0025 – 0030 – 0040 – 0060
PKG-SVX24B-IT
Maximum available pressure depending on the fan speed regulation:
UNITS WITH E.C. FANS
Nominal fan regulation (to have the nominal airow with ESP=20Pa
Allegato Generico
Tabelle
per manuali Amico
ALGC000078
Rev.0
C08003
Pag. 3 / 11
UNIT WITHOUT ELECTRICAL RESISTANCES UNIT WITH ELECTRICAL RESISTANCES
Rated speed @20Pa Minimum speed @20Pa Rated speed @20Pa Minimum speed @20Pa
Model
EU4 Eu4 +Post EU4 Eu4 +Post EU4 Eu4 +Post EU4 Eu4 +Post
[%] [%] [%] [%] [%] [%] [%] [%]
SDAC -SDWC
151 75 75 48 48 75 75 48 48
251 82 82 48 48 83 83 48 48
331 69 69 46 46 70 70 50 50
351 80 80 46 46 80 80 50 50
501
100 100 62 62 100 100 65 65
601
SUAC -SUWC
151 75 75 48 48 75 75 48 48
251 82 82 48 48 83 83 48 48
331 69 69 46 46 70 70 50 50
351 80 80 46 46 80 80 50 50
501
99 99 62 62 100 100 65 65
601
Massima pressione disponibile in funzione della regolazione della velocità del ventilatore:
J*AC J*WC 0115 - 0125
Air Flow
[m3/h]
1040 1300 1400 1500 1626
Fan Speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
48 14 - - - -
60 194 47 - - -
70 239 157 110 50 -
75 242 180 144 97 20
100 292 209 182 155 116
J*AC J*WC 0133 - 0135
Air Flow
[m3/h]
1940 2200 2500 2700 2977
Fan Speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
48 55 - - - -
60 209 151 63 - -
70 241 209 158 113 32
85 236 212 182 159 117
100 308 254 204 174 132
Allegato Generico
Tabelle
per manuali Amico
ALGC000078
Rev.0
C08003
Pag. 3 / 11
UNIT WITHOUT ELECTRICAL RESISTANCES UNIT WITH ELECTRICAL RESISTANCES
Rated speed @20Pa Minimum speed @20Pa Rated speed @20Pa Minimum speed @20Pa
Model
EU4 Eu4 +Post EU4 Eu4 +Post EU4 Eu4 +Post EU4 Eu4 +Post
[%] [%] [%] [%] [%] [%] [%] [%]
SDAC -SDWC
151 75 75 48 48 75 75 48 48
251 82 82 48 48 83 83 48 48
331 69 69 46 46 70 70 50 50
351 80 80 46 46 80 80 50 50
501
100 100 62 62 100 100 65 65
601
SUAC -SUWC
151 75 75 48 48 75 75 48 48
251 82 82 48 48 83 83 48 48
331 69 69 46 46 70 70 50 50
351 80 80 46 46 80 80 50 50
501
99 99 62 62 100 100 65 65
601
Massima pressione disponibile in funzione della regolazione della velocità del ventilatore:
J*AC J*WC 0115 - 0125
Air Flow
[m3/h]
1040 1300 1400 1500 1626
Fan Speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
48 14 - - - -
60 194 47 - - -
70 239 157 110 50 -
75 242 180 144 97 20
100 292 209 182 155 116
J*AC J*WC 0133 - 0135
Air Flow
[m3/h]
1940 2200 2500 2700 2977
Fan Speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
48 55 - - - -
60 209 151 63 - -
70 241 209 158 113 32
85 236 212 182 159 117
100 308 254 204 174 132
J*AC J*WC 0150 - 0160
Air Flow
[m3/h]
3000 3200 3700 4400 4482
Fan Speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
53 - - - - -
70 134 100 - - -
80 182 167 101 - -
85 183 173 125 - -
100 190 178 135 36 20
S*AV -S*WV 0331 - 0351
Portata
aria
[m3/h]
1940 2200 3205 3205 3440
Velocità
venlatore
Pressione staca di mandata
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
47 22 - - - -
55 93 53 - - -
70 249 210 18 18 -
75 305 265 73 73 18
85 410 370 178 178 123
S*AV S*WV 0501 - 0601
Portata
aria
[m3/h] 3020 3200 4500 5200 5320
Velocità
venlatore
Pressione staca di mandata
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
55 23 4 - - -
65 114 95 - - -
80 252 233 69 - -
90 317 299 135 22 0
100 335 317 153 40 19
Allegato Generico
Tabelle
per manuali Amico
ALGC000078
Rev.0
C08003
Pag. 4 / 11
S*AC S*WC 0331 - 0351
Flow rate
[m3/h]
1940 2200 2500 2700 2977
Fan speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
48 55 - - - -
60 209 151 63 - -
70 241 209 158 113 32
85 236 212 182 159 117
100 308 254 204 174 132
S*AC S*WC 0501 - 0601
Flow rate
[m3/h]
3000 3200 3700 4400 4482
Fan speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
53 - - - - -
70 134 100 - - -
80 182 167 101 - -
85 183 173 125 - -
100 190 178 135 36 20
UNITS WITH E.C. FANS
Nominal regulation of the fan (in order to have a nominal air flow of ESP=20Pa)
UNIT WITHOUT ELECTRICAL HEATERS UNIT WITH ELECTRICAL HEATERS
Nominal speed @20Pa Minimum speed @20Pa Nominal speed @20Pa Minimum speed @20Pa
Model
EU4 Eu4 +Post EU4 Eu4 +Post EU4 Eu4 +Post EU4 Eu4 +Post
[%] [%] [%] [%] [%] [%] [%] [%]
JDAV - JDWV
0115 68 68 47 47 68 68 47 47
0125 71 71 47 47 72 72 47 47
0133 70 70 46 46 70 70 50 50
0135 75 75 46 46 75 75 50 50
0150
84 84 54 54 86 86 57 57
0160
JUAV - JUWV
0115 75 75 48 48 75 75 48 48
0125 82 82 48 48 83 83 48 48
0133 69 69 46 46 70 70 50 50
0135 80 80 46 46 80 80 50 50
0150
99 99 62 62 100 100 65 65
0160
UNIT WITHOUT ELECTRICAL HEATERS
Nominal speed @20Pa Nominal speed @20Pa
Discharge static pressure
Air Flow
[m
3
/h]
Air Flow
[m
3
/h]
Air Flow
[m
3
/h]
Fan Speed
Fan Speed
Fan Speed
Discharge static pressure
Discharge static pressure
Minimum speed @20PaMinimum speed @20Pa
Model
UNIT WITH ELECTRICAL HEATERS
