Maximum available pressure depending on the fan speed regulation:
Allegato Generico
Tabelle
per manuali Amico
ALGC000078
Rev.0
C08003
Pag. 4 / 11
S*AC S*WC 0501 - 0601
Air Flow
[m3/h]
3000 3200 3700 4400 4482
Fan Speed Pressione staca di mandata
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
53 - - - - -
70 134 100 - - -
80 182 167 101 - -
85 183 173 125 - -
100 190 178 135 36 20
UNITA’ CON VENTILATORI RADIALI E.C.
UNIT WITHOUT ELECTRICAL RESISTANCES UNIT WITH ELECTRICAL RESISTANCES
Rated speed @20Pa Minimum speed @20Pa Rated speed @20Pa Minimum speed @20Pa
Model
EU4 Eu4 +Post EU4 Eu4 +Post EU4 Eu4 +Post EU4 Eu4 +Post
[%] [%] [%] [%] [%] [%] [%] [%]
SDAV -SDWV
151 68 68 47 47 68 68 47 47
251 71 71 47 47 72 72 47 47
331 70 70 46 46 70 70 50 50
351 75 75 46 46 75 75 50 50
501
84 84 54 54 86 86 57 57
601
SUAV -SUWV
151 75 75 48 48 75 75 48 48
251 82 82 48 48 83 83 48 48
331 69 69 46 46 70 70 50 50
351 80 80 46 46 80 80 50 50
501
99 99 62 62 100 100 65 65
601
Massima pressione disponibile in funzione della regolazione della velocità del ventilatore:
J*AV - J*WV 0115 - 0125
Air Flow
[m3/h]
1040 1300 1400 1500 1626
Fan Speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
49 34 - - - -
60 137 57 22 - -
70 245 164 129 91 40
80 354 274 239 201 150
85 406 325 290 252 201
Allegato Generico
Tabelle
per manuali Amico
ALGC000078
Rev.0
C08003
Pag. 5 / 11
J*AV - J*WV 0133 - 0135
Air Flow
[m3/h]
1940 2200 3205 3205 3440
Fan Speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
47 22 - - - -
55 93 53 - - -
70 249 210 18 18 -
75 305 265 73 73 18
85 410 370 178 178 123
J*AV J*WV 0150 - 0160
Air Flow
[m3/h]
3020 3200 4500 5200 5320
Fan Speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
55 23 4 - - -
65 114 95 - - -
80 252 233 69 - -
90 317 299 135 22 0
100 335 317 153 40 19
UNITA’ AD ACQUA REFRIGERATA - VENTILATORI CENTRIFUGHI
Modello
0200B 0250B 0300B 0400B 0600B
2
0471 0471 0471 0471 0471 mm azzetlA
058 055 055 055 055 mm azzehgraL
PAGINA 31
Allegato Generico
Tabelle
per manuali Amico
ALGC000078
Rev.0
C08003
Pag. 5 / 11
J*AV - J*WV 0133 - 0135
Air Flow
[m3/h]
1940 2200 3205 3205 3440
Fan Speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
47 22 - - - -
55 93 53 - - -
70 249 210 18 18 -
75 305 265 73 73 18
85 410 370 178 178 123
J*AV J*WV 0150 - 0160
Air Flow
[m3/h]
3020 3200 4500 5200 5320
Fan Speed Discharge stac pressure
[%] [Pa] [Pa] [Pa] [Pa] [Pa]
55 23 4 - - -
65 114 95 - - -
80 252 233 69 - -
90 317 299 135 22 0
100 335 317 153 40 19
UNITA’ AD ACQUA REFRIGERATA - VENTILATORI CENTRIFUGHI
Modello
0200B 0250B 0300B 0400B 0600B
2
0471 0471 0471 0471 0471 mm azzetlA
058 055 055 055 055 mm azzehgraL
PAGINA 31
Discharge static pressure
Air Flow
[m
3
/h]
Air Flow
[m
3
/h]
Air Flow
[m
3
/h]
Fan Speed
Fan Speed
Fan Speed
Discharge static pressure
Discharge static pressure
