RLC-SVX09Q-EN
29
Table 12. Isolator part numbers and dimensions
Size Hz Effic.
Isolator Type
Maximum
Deflection
(in)
Dimension - in (mm)
Color [Ext]
(a)
Max Load-lbs (kg)
A B C D E H L W
80, 90, 100, 110,
120, 130, 140
60 STD
RDP-4
Red [62]
2250 (1021)
0.50
3.0
(76.2)
0.50
(12.7)
5.00
(127.0)
0.56
(14.2)
0.38
(9.7)
2.75
(69.8)
6.25
(158.8)
4.63
(117.6)
80, 90, 100, 110,
120, 130
60 HIGH
150, 160, 180,
200, 220, 250
60 HIGH
RDP-4
Green [63]
3000 (1361)
0.50
3.0
(76.2)
0.50
(12.7)
5.00
(127.0)
0.56
(14.2)
0.38
(9.7)
2.75
(69.8)
6.25
(158.8)
4.63
(117.6)
150, 160,
180, 200
60 PREM
Note: See submittal drawing to verify correct isolators.
(a)
Part number is X10140305-xx
Corner Weights
Figure 12. Mounting point locations and weights – RTWD Std efficiency (all), RTWD High efficiency: 80 - 120T (60 Hz)
Installation - Mechanical
