WARNING
Follow EHS Policies!
Failure to follow instructions below could result in
death or serious injury.
• All Trane personnel must follow the company’s
E
n
vironmental, Health and Safety (EHS) policies
when performing work such as hot work, electrical,
fall protection, lockout/tagout, refrigerant handling,
etc. Where local regulations are more stringent than
these policies, those regulations supersede these
policies.
• Non-Trane personnel should always follow local
regu
lati
ons.
Introduction
CDUB-SVN001B-EN 3
Copyright
This document and the information in it are the property of
Trane, and may not be used or reproduced in whole or in
part without written permission. Trane reserves the right
to revise this publication at any time, and to make changes
to its content without obligation to notify any person of
such revision or change.
Trademarks
All trademarks referenced in this document are the
trademarks of their respective owners.
Other Required Manuals
This manual must be used with the following publications
(or their most recent versions):
• CVHE-SVX005*-EN
1
, Installation, Operation, and
Maintenance - CVHE, CVHF, and CVHG Water-Cooled
CenTraVac™ Chillers With Symbio Control
• CTV-SVU004*-EN1, Operations Guide - Tracer®
A
daptiView™Display for CenTraVac™Water-Cooled
Chillers with Symbio
• CTV-SVP004*-EN1, Tracer TU
Service Tool for Water-
Cooled CenTraVac Chillers with Symbio Control
• CTV-SVD005*-EN1, Diagnostics Manual - Di
agnostic
Descriptions, Troubleshooting Tables, and Control
Component Overview for Water-Cooled CenTraVac™
Chillers with Tracer AdaptiView™ Control
• BAS-SVU047*-EN1, G
etting Started Guide: TU Service
To
ol
• CVRF-SVP01*-EN, Pro
g
ramming Guide: Tracer
Symbio Panel Upgrade
Required Tools
Normal service tools are required to perform the majority
of the work. A service technician with a well stocked tool
chest should have the right tools to perform the job.
In addition to the normal service to
ols
and hardware, the
following is a partial list of specific field supplied
hardware/software components and special tools that are
also required to perform the display retrofit:
• An RS-232 male DB9 to femal
e DB9 pi
n to pin serial
cable to connect the DynaView to a PC or laptop
computer.
Note: T
he cable must not be a “null-modem” cable.
The
cable must be less than 50 feet in length.
The RadioShack
®
part number for the proper cable is
26-117B.
• Type A to Type B USB cable to connect the Sym
b
io 800
controller to a PC or laptop computer.
• A PC or laptop computer equipped with the following:
– TechView™ service software, version 12.1 or
newer.
– Tracer TU service software, version 2.02 or newer.
– Rover™ service software (only required if the
chiller
is equippe
d with a LonTalk
®
Comm5 board).
• South pole magnet scre
wdriver (TOL01343).
• Electronics vacuum.
Field-Provided Material
Some field provided material will be required to perform
the display retrofit. A list of material is provided here to
help the technician to plan ahead and to avoid material
shortages at the job site.
• Wire, red and green #16 AWG control wire - required to
make the connections
between the power supply and
existing transformer.
• Wire connectors.
• Wire wrap or some other form of wire protection for
ar
e
as that wiring runs may come into contact with
sharp edges.
• Cable ties to help “clean up” wiring runs.
If the unit is located outside, a cover is required for the
display.
The Trane
®
part number for this cover is COV03916.
Revision History
Updated the Getting Started, Installation, Programming
chapters.
