Digital output
Programmable digital/pulse outputs 2
Terminal number 27, 29
1)
Voltage level at digital/frequency output 0-24 V
Max. output current (sink or source) 40 mA
Max. load at frequency output 1 kΩ
Max. capacitive load at frequency output 10 nF
Minimum output frequency at frequency output 0 Hz
Maximum output frequency at frequency output 32 kHz
Accuracy of frequency output Max. error: 0.1 % of full scale
Resolution of frequency outputs 12 bit
1)
Terminal 27 and 29 can also be programmed as input.
The digital output is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
Control card, 24 Vdc output
Terminal number 12, 13
Max. load 200 mA
The 24 Vdc supply is galvanically isolated from the supply voltage (PELV), but has the same potential as the analog and digital
inputs and outputs.
Relay outputs
Programmable relay outputs 2
Relay 01 Terminal number 1-3 (break), 1-2 (make)
Max. terminal load (AC-1)
1)
on 1-2 (NO) (Resistive load)
2)3)
400 Vac, 2 A
Max. terminal load (AC-15)
1)
on 1-2 (NO) (Inductive load @ cosφ 0.4) 240 Vac, 0.2 A
Max. terminal load (DC-1)
1)
on 1-2 (NO) (Resistive load) 80 Vdc, 2 A
Max. terminal load (DC-13)
1)
on 1-2 (NO) (Inductive load) 24 Vdc, 0.1 A
Max. terminal load (AC-1)
1)
on 1-3 (NC) (Resistive load) 240 Vac, 2 A
Max. terminal load (AC-15)
1)
on 1-3 (NC) (Inductive load @ cosφ 0.4) 240 Vac, 0.2 A
Max. terminal load (DC-1)
1)
on 1-3 (NC) (Resistive load) 50 Vdc, 2 A
Max. terminal load (DC-13)
1)
on 1-3 (NC) (Inductive load) 24 Vdc, 0.1 A
Min. terminal load on 1-3 (NC), 1-2 (NO) 24 Vdc 10 mA, 24Vac 2 mA
Environment according to EN 60664-1 overvoltage category III/pollution degree 2
Relay 02 Terminal number 4-6 (break), 4-5 (make)
Max. terminal load (AC-1)
1)
on 4-5 (NO) (Resistive load)
2)3)
400 Vac, 2 A
Max. terminal load (AC-15)
1)
on 4-5 (NO) (Inductive load @ cosφ 0.4) 240 Vac, 0.2 A
Max. terminal load (DC-1)
1)
on 4-5 (NO) (Resistive load) 80 Vdc, 2 A
Max. terminal load (DC-13)
1)
on 4-5 (NO) (Inductive load) 24 Vdc, 0.1 A
Max. terminal load (AC-1)
1)
on 4-6 (NC) (Resistive load) 240 Vac, 2 A
Max. terminal load (AC-15)
1)
on 4-6 (NC) (Inductive load @ cosφ 0.4) 240 Vac, 0.2 A
Max. terminal load (DC-1)
1)
on 4-6 (NC) (Resistive load) 50 Vdc, 2 A
Max. terminal load (DC-13)
1)
on 4-6 (NC) (Inductive load) 24 Vdc, 0.1 A
Min. terminal load on 4-6 (NC), 4-5 (NO) 24 Vdc 10 mA, 24Vac 2 mA
Environment according to EN 60664-1 overvoltage category III/pollution degree 2
1)
IEC 60947 t 4 and 5
The relay contacts are galvanically isolated from the rest of the circuit by reinforced isolation (PELV).
2)
Overvoltage Category II
3)
UL applications 300 Vac 2 A
Control card, 10 V DC output
Terminal number 50
Output voltage 10.5 V ±0.5 V
Max. load 25 mA
The 10 Vdc supply is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
