Trane Tracer MP503 User Manual

Operating environment
CNT-SVX09B-EN 3
Figure 1. MP503 plastic-cover model dimensions and clearances
Figure 2. MP503 metal-cover model dimensions and clearances
4 in.
(102 mm)
1 in.
(25 mm)
5.625 in.
(143 mm)
5.375 in. (137 mm)
1 in.
(25 mm)
6.31 in.
(160 mm)
4 in.
(102 mm)
4 in.
(102 mm)
2 in. (51 mm)
6.875 in.
(175 mm)
Clearances
Dimensions
1 in.
(25 mm)
9 in.
(229 mm)
2 in.
(51 mm)
24 in.
(610 mm)
10.37 in.
(263 mm)
width with cover
1 in.
(25 mm)
2.25 in.
(58 mm)
Clearances
Dimensions
2 in.
(51 mm)
0.28 in.
(7 mm)
9 in.
(229 mm)
6.5 in.
(165 mm)
1.875 in.
(48 mm)
7 in.
(178 mm)
1 in.
(25 mm)
10.25 in.
(260 mm)
width without cover
