10
SETUP MENU PROCEDURES
This section provides instructions for all of the Setup Menu procedures except F16 through F20. Those
procedures can be found in the Calibration section.
Key-in Operation (F1, F5, F11, F31, F34 and F36)
Follow these general instructions for those parameters requiring keyed-in data:
1. While in the Setup mode, scroll to "F xx", and then scroll down once using the ZERO key.
The display will momentarily show a brief description, followed the currently stored value.
2. If the displayed value is correct, simply press the ENTER or C/CE key to escape.
3. If the displayed value needs to be changed, use the front panel numeric keys to key-in the
new value and then press ENTER. If you make a mistake, press the C/CE key as a
backspace key. The display will show "Set" momentarily, and then revert back up to "F xx".
Fine-tune 4-20 mA output (F23)
1. While in the Setup Menu mode, scroll to "F 23", then scroll down once using the ZERO key to
enter Fine-tune menu. The indicator outputs 4 mA and displays a number.
2. While monitoring the voltage across R
L
(see Appendix E), use the right (PRINT) or left
(TARE) keys to change the displayed value until the measured voltage is exactly 1 VDC.
3. Press the SET (Mode) key to save. The indicator outputs 20 mA and displays another
number.
4. While monitoring the voltage across R
L
, use the right (PRINT) or left (TARE) keys to change
the displayed value until the measured voltage is exactly 5 VDC.
5. Press the SET (Mode) key to save and revert back to F23.
