Transcell Technology TI-1680 User Manual

34
OUTPUT STRING
The indicator contains one editable output string (print format). You can simply choose one of three
output strings already created for you or you can edit one of the pre-defined output strings to suit your
application.
Output strings are created by assigning a hexadecimal value to a decimal address. The addresses
start at 0 (displayed as 00) and end at 94. The HEX value can be a printable ASCII character or a
print command. Below please find a table of print commands.
Print Commands
Dec
Hex
Printing Action
(abbrev.)
Parameter
128
80
Gross weight
(GWT)
129
81
Net weight
(NWT)
130
82
Tare weight
(TWT)
131
83
Print the
data on screen
(CWT)
132
85
Units (lb, kg, PCS
, etc
)
(UN)
133
86
Date
(DAT)
134
87
Time
(TIM)
135
88
‘O’ = Over/Under; ‘M’=Motion
(STAT)
136
89
Gross/Net flag: ‘G/N’
(GN)
137
8A
MP20 print
er
to print header info.
(MP20)
149
8C
Print out ID
number.
(PRID)
140
8D
No. of line feeds.
(PRLF)
1
-
99 (Dec)
141
8E
No. of spaces.
(PRSPS)
1
-
99 (Dec)
142
90
Unit flag: ‘L/K’
(LK)
143
91
Unit flag: ‘LB/KG’
(LBKG)
144
92
Gross/Net flag: ‘GR/NT’
(GRNT)
145
93
Gross Total Weight
(GTOT)
146
94
Net
Total Weight
(
N
TOT)
147
95
Transaction Number
(TRANS)
148
96
Pieces
(PRPCS)
14
9
97
Percentage
(PRPC
T
)
0
00
Null
(NUL)
255
FF
End of String
(EOS)
NOTES:
1. The decimal values are provided only for reference; use HEX values when programming.
2. All output strings should end with an EOS character.
3. The Null character can be used to comment out a line when editing pre-defined output strings. In
this manner an unnecessary line can simply be skipped, i.e. not printed.
