STRING FORMAT 2 (Condec Continuous String)
String Format 2 is designed for one-way communication, e.g. remote display.
<STX> <POL> xxxxx.xx <L/K> <G/N> <STAT> <CR> <LF>
Polarity:
<SP> = Positive
"–" = Negative
Weight Data
Units:
L = pound
K = kilogram
Gross/Net:
G = Gross
N = Net
Start
Transmission
Carriage
Return
Line
Feed
Status:
<SP> = Valid
M = Motion
O = Over/under range
P = pieces
C = custom units
PCS = pieces
Address
(Dec)
Value
(Hex)
Chart
Address
(Dec)
Value
(Hex)
Charts
00
02
STX
01
83
(CWT)
02
90
(LK)
03
89
(GN)
04
88
(STAT)
05
0D
CR
06
0A
LF
07
FF
EOS
