38
Edit Output String (A14)
The programming format is AA__vv where AA is the address (00 to 94) and vv is the programming
value (remember a value can be either a printable ASCII character or a print command.)
1. While in the User Menu mode, scroll to "A 14", and then scroll down once using the ZERO key to
the A14 U1 level.
2. Use the Use the right arrow key (PRINT) to select the A 14 U1 or A14 U2 menu.
3. At the A14 Ux screen, scroll down once using the ZERO key to enter the edit output string menu.
The display will show the programming format, e.g. 00 49 where 00 is address 0 and 49 is the
current programming value in hex.
4. Use the right arrow key (PRINT) to increase the address by one. Use the left arrow key (TARE) to
decrease the address by one.
5. After selecting the address you want to change, press the MODE key. The programming value will
start flashing. Increase the flashing digit by pressing the UNITS key. Decrease the flashing digit by
pressing the ZERO key. Pressing the PRINT key or the TARE key will change the position of the
flashing digit.
6. After setting the exact programming value, press the MODE key to save. The indicator will
automatically increment to the next address.
7. Repeat Steps 3 and 4 until the entire output string has been programmed.
8. Press the UNITS key to exit A14 menu mode.
