9 INSTALLING THE CHAIN KEEPER
TOOLS AND MATERIALS REQUIRED
• Hex bolt
• Chain keeper washer
• Chain keeper
1. Pass the bolt through the washer,
and then the chain keeper.
2. Thread the bolt into the frame,
and tighten until finger tight.
IMPORTANT
Do not adjust the chain keeper yet. Final adjustment
should wait until after the crank is installed.
