15 SERVICE INFORMATION
The Madone 9 series IsoSpeed technology utilizes an internal seat tube that was engineered to move during normal riding
conditions. To prevent water bottle screws from inhibiting this movement, the threaded water bottle mounting holes are
designed with a depth stop, meaning the hole has a bottom. To properly mount a water bottle cage to the seat tube, M5 x
10mm screws included with the bike must be used. If the screw tightening maximum torque is reached and the cage isn’t
tight, a washer may be added under the head of the screw. Proper water bottle screw torque is 20-25lb*in (2.3-2.9Nm)
for the steel bolts supplied with the bike.
Madone 9 Series Seat Tube Water Bottle Screws
date miles/km
SERVICE NOTES
30
