TRENDnet TEW-831DR User Manual

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TEW-831DR
27
Please refer to page 18 to find out about different security types and page 19 for
wireless security configuration.
The diagram shows an example of a client connecting to SSID 1 and another client
connecting to SSID 2.
5. To save changes to this section, click Save when finished. Commit your changes to the
router by clicking on Apply/Discard Changes in the left-hand menu, and click Apply &
Reboot.
Note: You can repeat the steps to enable and configure additional SSIDs.
Wireless bridging using WDS (Wireless Distribution System)
Advanced > Wireless (2.4GHz or 5GHz) > WDS
Wireless bridging using WDS allows the device to create a wireless bridge with other
WDS supported wireless routers and access points configured in WDS mode to bridge
groups of network devices together wirelessly. Simultaneously, the router will also
function in access point mode allowing wireless client devices such as computers, game
consoles, mobile phones, etc. to connect in order to access network resources from
multiple groups of network devices as well as the Internet.
Note: You can create up to four WDS bridge connections on each wireless band (2.4GHz
and 5GHz. WDS (Wireless Distribution System) is not currently standardized and may not
connect to different model wireless routers or access points, therefore, when using WDS,
it is recommended to use the same model and version for wireless bridging.
By default, your router functions in Access Point mode to allow wireless client devices to
connect and access your network resources and access the Internet.
The diagram below shows your router in Access Point mode and clients connecting to
your router.

TRENDnet TEW-831DR Specifications

General

Product color	Black
Cables included	LAN (RJ-45)
Quick installation guide	Yes
Certification	FCC, IC
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Output current	1 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
DSL WAN	No
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1200 Mbit/s
VPN support	FTP/TFTP/SIP/RTSP/IRC/H.323
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Receiver sensitivity	802.11a: -75 dBm @ 54Mbps 802.11b: -90 dBm @ 11Mbps 802.11g: -72 dBm @ 54Mbps 802.11n (2.4GHz): -72 dBm @ 300Mbps 802.11n (5GHz): -72 dBm @ 867Mbps 802.11ac: -61 dBm @ 867Mbps
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Antennas quantity	4
Antenna gain level (max)	5 dBi
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2
Number of products included	1 pc(s)
Ethernet LAN (RJ-45) ports	3

Weight and Dimensions

Depth	239 mm
Width	155 mm
Height	30 mm
Weight	228 g
