FTP (File Transfer Protocol) Server
Advanced > USB > FTP
FTP (File Transfer Protocol) is used to access shared files through the Internet. In order
to share files, you will need to plug in a USB storage device on the USB port on the back
of the router.
1. Log into your router management page (see “Access your router management page”
on page 10).
2. Click on Advanced and click on USB, then click on FTP Server.
3. Review the administrator settings required for your FTP server. Click Apply to save
settings. Commit your changes to the router by clicking on Apply/Discard Changes in
the left-hand menu, and click Apply & Reboot.
 FTP Server: Select enable or disable for the feature.
 Authentication: Selecting Enable will require user name and password
authentication in order to access the USB storage using FTP. Selecting Disable will
disable the user name and password authentication requirement for access the
USB storage which can be access anonymously.
 Access From Internet: Selecting Enable will allow access to the USB storage using
FTP over the Internet (WAN) and local (LAN) networks. Selecting Disable will
disable FTP access over the Internet and allow LAN access only.
 File Server Codepage: Defines which character set to use when transferring data
using FTP. It is recommended to leave these settings as default “Western
European”.
4. Review the User Account List section. Click Add to add the account.
 User Name: Enter the user name to be used to access your files.
 Password: Enter the password for the user name.
 Permission: Select the permission you will grant to the user. You can allow the
user Read Only or Read-Write access to the USB storage.
Signing up for a Dynamic DNS service (outlined in Identify Your Network section pg.39)
will provide identification of the router’s network from the Internet. You can access your
shared files over the Internet by typing ex.錯誤! 超連結參照不正確。> or
ftp://myDDNSservice in your web browser or file explorer address bar. You can access
your share files locally by typing 錯誤! 超連結參照不正確。> in your web browser or
file explorer address bar.
You can find your router’s WAN IP address settings under Advanced > Administrator >
Status.

TRENDnet TEW-831DR Specifications

General

Product color	Black
Cables included	LAN (RJ-45)
Quick installation guide	Yes
Certification	FCC, IC
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Output current	1 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
DSL WAN	No
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1200 Mbit/s
VPN support	FTP/TFTP/SIP/RTSP/IRC/H.323
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Receiver sensitivity	802.11a: -75 dBm @ 54Mbps 802.11b: -90 dBm @ 11Mbps 802.11g: -72 dBm @ 54Mbps 802.11n (2.4GHz): -72 dBm @ 300Mbps 802.11n (5GHz): -72 dBm @ 867Mbps 802.11ac: -61 dBm @ 867Mbps
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Antennas quantity	4
Antenna gain level (max)	5 dBi
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2
Number of products included	1 pc(s)
Ethernet LAN (RJ-45) ports	3

Weight and Dimensions

Depth	239 mm
Width	155 mm
Height	30 mm
Weight	228 g
