Check the router system information
Advanced > Administrator > Status
You may want to check the system information of your router such as WAN (Internet)
connectivity, wireless and wired network settings, router MAC address, and firmware
version.
1. Log into your router management page (see “Access your router management page”
on page 10).
2. Click on Advanced and click on Administrator, then click on Status
System Information
 Firmware Version – The current firmware version your router is running.
 Time: The current time set on your router.
 System Up Time – The duration your router has been running continuously
without a restart/power cycle (hard or soft reboot) or reset.
Internet Configuration
 Connected Type: Displays the current WAN connection type applied.
 WAN IP Address – The current IP address assigned to your router WAN port or
interface configuration.
 WAN MAC Address: Displays the current WAN MAC address.
 Subnet Mask - The current subnet mask assigned to your router WAN port or
interface configuration.
 Default Gateway – The current gateway assigned to your router WAN port or
interface configuration.
 Primary/Secondary DNS (Domain Name System) Server – The current DNS
address(es) assigned to your router port or interface configuration.
 DHCP WAN Type: These buttons will be available in DHCP WAN type only.
o Renew: Click this option to renew your WAN IP address.
o Release: Click this option to release the WAN IP address of your
router.
 PPPoE WAN Type: These buttons will be available in DHCP WAN type only.
o Connect: Click this option to connect to your DSL ISP
o Disconnect: Click this option to disconnect from your DSL ISP.

TRENDnet TEW-831DR Specifications

General

Product color	Black
Cables included	LAN (RJ-45)
Quick installation guide	Yes
Certification	FCC, IC
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Output current	1 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
DSL WAN	No
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1200 Mbit/s
VPN support	FTP/TFTP/SIP/RTSP/IRC/H.323
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Receiver sensitivity	802.11a: -75 dBm @ 54Mbps 802.11b: -90 dBm @ 11Mbps 802.11g: -72 dBm @ 54Mbps 802.11n (2.4GHz): -72 dBm @ 300Mbps 802.11n (5GHz): -72 dBm @ 867Mbps 802.11ac: -61 dBm @ 867Mbps
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Antennas quantity	4
Antenna gain level (max)	5 dBi
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2
Number of products included	1 pc(s)
Ethernet LAN (RJ-45) ports	3

Weight and Dimensions

Depth	239 mm
Width	155 mm
Height	30 mm
Weight	228 g
