TRENDnet TEW-831DR User Manual

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TEW-831DR
2
Features
TRENDnet’s AC1200 Dual Band WiFi Router, model TEW-831DR, is a high-speed wireless
ac router designed to handle multiple HD streams in a busy connected home. This dual
band wireless ac router creates two concurrent wireless networks—a high performance
867Mbps wireless AC network, and a 300Mbps wireless N network for wireless device
connections. For added convenience, the wireless networks are pre-encrypted out of
the box.
Pre-Encrypted
For your convenience, the wireless networks are pre-encrypted with unique passwords.
5dBi External Antennas
4 x 5dBi external antennas provide extended wireless coverage.
Internet Bandwidth Controls
Control access to the internet and manage bandwidth for devices connected to the
wireless ac router.
Easy Setup
Install in minutes with the intuitive setup
One Touch Connection
Connect to the wireless ac router using the Wi-Fi Protected Setup (WPS) button
Pre-Encrypted
For your convenience, the wireless network is pre-encrypted with its own unique
password
Access Controls
Control access to specific websites and manage which devices can access the internet
Fast Ethernet Ports
10/100 Mbps Ethernet ports connect up to three devices
Wireless Coverage
4 x 5dBi antennas on this wireless ac router provide extended wireless coverage
IPv6
IPv6 network support
*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual
data throughput and coverage will vary depending on interference, network traffic, building
materials, and other conditions. For maximum performance of up to 867Mbps, use with an
867Mbps 802.11ac wireless adapter. For maximum performance of up to 300Mbps, use with a
300Mbps 802.11n wireless adapter. Multi-User MIMO (MU-MIMO) requires the use of multiple
MU-MIMO enabled wireless adapters.
**Due to regulatory requirements, the wireless channels specified cannot be statically assigned,
but will be available within the available wireless channels when set to auto.

TRENDnet TEW-831DR Specifications

General

Product color	Black
Cables included	LAN (RJ-45)
Quick installation guide	Yes
Certification	FCC, IC
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Output current	1 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
DSL WAN	No
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1200 Mbit/s
VPN support	FTP/TFTP/SIP/RTSP/IRC/H.323
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Receiver sensitivity	802.11a: -75 dBm @ 54Mbps 802.11b: -90 dBm @ 11Mbps 802.11g: -72 dBm @ 54Mbps 802.11n (2.4GHz): -72 dBm @ 300Mbps 802.11n (5GHz): -72 dBm @ 867Mbps 802.11ac: -61 dBm @ 867Mbps
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Antennas quantity	4
Antenna gain level (max)	5 dBi
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2
Number of products included	1 pc(s)
Ethernet LAN (RJ-45) ports	3

Weight and Dimensions

Depth	239 mm
Width	155 mm
Height	30 mm
Weight	228 g
