TRENDnet User’s Guide
TEW-831DR
45
Access Control (IP Protocol Filter)
Advanced > Security > Access Control
You may want to block computers or devices on your network access to specific ports
(used or required by a specific application) to the Internet.
Block a specific service or multiple services
1. Log into your router management page (see “Access your router management page”
on page 10).
2. Click on Advanced and click on Security, then click on Access Control.
3. Next to Enable Access Control, click the Enable option.
4. Review the Add Services Block Rule. Click Add to save the rule. Commit your changes
to the router by clicking on Apply/Discard Changes in the left-hand menu, and click
Apply & Reboot.
 Rule Enable – Checking this option turns on the Protocol/IP Filter and
unchecking turns it off.
 Rule Name – Enter a name for the Protocol/IP Filter.
 Schedule (Optional) – The schedule function allows you to define a schedule
when the access control filter should be turned on. T To define a new schedule,
click New Schedule and refer to page 42 “ Create Schedules”. After you have
created a new schedule, click the drop-down list and the new schedule will be
available for selection. Note: Before applying scheduling, please ensure your Time
settings are configured correct and you have defined a schedule. See page 41 to
configure Time Settings and see page 42 “ Create Schedules” to create a schedule.
 Client IP Address Range – Enter the IP address or IP address range to apply the
protocol/IP filter. (e.g. 192.168.10.20-192.168.10.20 or 192.168.10.20-
192.168.10.30).
Note: The filter will not be applied to IP addresses outside of the range
specified.
To simplify configuration, there is a list of commonly used pre-defined Protocol/IP Filters
to modify otherwise, you can choose to manually add a new Protocol/IP Filter.
 Service – Select Predefined to select from the predefined services listed or
select Manually to specifically enter the TCP or UDP port number or port range
numbers to block. (e.g. 80-80 or 20-21).

TRENDnet TEW-831DR Specifications

General

Product color	Black
Cables included	LAN (RJ-45)
Quick installation guide	Yes
Certification	FCC, IC
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Output current	1 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
DSL WAN	No
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1200 Mbit/s
VPN support	FTP/TFTP/SIP/RTSP/IRC/H.323
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Receiver sensitivity	802.11a: -75 dBm @ 54Mbps 802.11b: -90 dBm @ 11Mbps 802.11g: -72 dBm @ 54Mbps 802.11n (2.4GHz): -72 dBm @ 300Mbps 802.11n (5GHz): -72 dBm @ 867Mbps 802.11ac: -61 dBm @ 867Mbps
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Antennas quantity	4
Antenna gain level (max)	5 dBi
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2
Number of products included	1 pc(s)
Ethernet LAN (RJ-45) ports	3

Weight and Dimensions

Depth	239 mm
Width	155 mm
Height	30 mm
Weight	228 g
