TRENDnet User’s Guide
TEW-831DR
4
Front View
No
Item
Description
1
Power LED
Solid Blue – Device is on
Off – No power
2
WPS LED
Blinking Blue – WPS is activated.
Off – WPS not activated
3
2.4G Wireless LEDs
Solid Blue – 2.4GHz radio is on.
Blinking Blue – Data Transmit/Receive.
Off – 2.4GHz radio is off.
4
5G Wireless LEDs
Solid Blue – /5GHz radio is on.
Blinking Blue – Data Transmit/Receive.
Off – 5GHz radio is off.
Application Diagram
