© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TEW-831DR
54
Samba (SMB) Server: Select enable or disable for the feature.
Server Name: You can change the name of your server which will be the name
you will when accessing your USB storage device. (Note: You can also access the
USB storage using the router IP address)
Workgroup: Enter the workgroup name. It is recommended to keep the standard
default “WORKGROUP”. If you change this setting, you will need to change the
workgroup name on all computers in your network that are allowed access to the
USB storage in order to discover it automatically. Otherwise, you will need to
access the server by IP address.
Description (optional): Enter a description of the server.
4. Review the administrator settings required for your File Sharing (SMB) Server. Click
Apply to save settings. Administrator will have read and write access to files. To
define user accounts continue to the next step.
Note: For security purposes, the default administrator user name and password are set
to your predefined user name and password setting to access the router management
page.
User Name: Enter the user name to be used to access your files.
Password: Enter the password for the user name. Re-type Password to confirm.
5. Review the User Account List section. Click Add to add the account.
User Name: Enter the user name to be used to access your files.
Password: Enter the password for the user name.
Permission: Select the permission you will grant to the user. You can allow the
user Read Only or Read-Write access to the USB storage.
Under Windows®, you can access the USB storage device on your computer under
Computer > Network > USBSHARE > usb_A1.
Note: Your computer will only be able to automatically discover the USB storage if you
are set to a workgroup under the default name “WORKGROUP”. Your computer will not
be able to automatically discover the USB storage device if under a domain or different a
workgroup name.
Under Windows®, if your computer cannot discover the USB storage automatically, you
can access these files under your network map or by typing 錯誤! 超連結參照不正確。
(ex. \\192.168.10.1\usb_A1) on your browser’s or file explorer address bar. Please
follow the below steps to configure the router’s SMB settings

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TRENDnet TEW-831DR and is the answer not in the manual?

TRENDnet TEW-831DR Specifications

General IconGeneral
Product colorBlack
Cables includedLAN (RJ-45)
Quick installation guideYes
CertificationFCC, IC
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)0 - 90 %
Output current1 A
Output voltage12 V
AC input voltage100 - 240 V
Power source typeAC
AC input frequency50 - 60 Hz
DSL WANNo
Modulation16-QAM, 64-QAM, 256-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1200 Mbit/s
VPN supportFTP/TFTP/SIP/RTSP/IRC/H.323
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Receiver sensitivity802.11a: -75 dBm @ 54Mbps 802.11b: -90 dBm @ 11Mbps 802.11g: -72 dBm @ 54Mbps 802.11n (2.4GHz): -72 dBm @ 300Mbps 802.11n (5GHz): -72 dBm @ 867Mbps 802.11ac: -61 dBm @ 867Mbps
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Antennas quantity4
Antenna gain level (max)5 dBi
Security algorithms64-bit WEP, 128-bit WEP, WPA, WPA2
Number of products included1 pc(s)
Ethernet LAN (RJ-45) ports3
Weight and Dimensions IconWeight and Dimensions
Depth239 mm
Width155 mm
Height30 mm
Weight228 g
