© Copyright 2014 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TEW-815DAP
25
5. Click the Wireless Channel drop-down list and select a specific wireless channel.(ex.
2.462GHz - CH 11)
6. Under the WDS section, next to Remote AP MAC Address1, enter the wireless MAC
address of the remote WDS supported access point or router.
Note: Based on the example, enter the remote 2.4GHz wireless MAC address of
AP2.(00:11:22:AA:BB:C3)
Note: You can also use the site survey option to scan for your remote WDS supported
device broadcasting (AP or WDS+AP), then select and connect to copy the wireless
MAC addresses of your other WDS supported devices. This simplifies the process of
having to write down the wireless MAC addresses of all devices and manually enter.
7. Configure the wireless security settings and wireless key.
Note: Please refer to page 10 “
Wireless Networking and Security” for details on
configuring wireless security settings.
8. Click Apply.
AP2 Configuration
1. Log into your access point management page (see “
Access your access point
management page” on page 7).
2. Click on Wireless, click on Basic and scroll down to Wireless Network Settings -
(2.4GHz or 5GHz). Note: For this example, 2.4GHz band will be used which also
matches the band used for AP1.
3. Click the Mode drop-down list and select one of following WDS options. Note: WDS or
WDS+AP modes can work with each other between WDS support devices.
• WDS: Select this option to establish wireless bridging only without broadcasting
your wireless network name for client devices to connect. Please refer to the
section
Wireless Bridge (WDS) Mode page 18 for details on this mode.
• WDS+AP (Recommended): Select this option to establish wireless bridging and
broadcast your wireless network name for client devices to connect simultaneously.
Please refer to the section
Wireless Bridge (WDS) with Access Point (AP) Mode on
page 20 for details on this mode.
