1.
Connect the x/e-touchPANEL to the PC/laptop using a crossed network cable.
Set the following values on the PC/laptop for the network card to which the x/e-touchPANEL is connected:
IP Address: 192.168.123.10
Subnet mask: 255.255.255.0
Gateway: 192.168.123.1
Set the following values for the x/e-touchPANEL:
IP Address: 192.168.123.11
Subnet mask: 255.255.255.0
Gateway: 192.168.123.1
To store the IP address in the x/e-touchPANEL, click on the Main menu symbol.
-> The x/e-touchPANEL can be controlled via remote control using a web browser with Java Applet installed.
7.4.6. Establishing a connection to the x/e-touchPANEL
The remote control of the x/e-touchPANEL is based on an HTML page with Java-Applet.
In order to operate the x/e-touchPANEL on a PC/laptop, the ›Java Runtime Environment (JRE)‹ must be installed on
the PC/laptop (www.java.com). A standard web browser is used for the connection (e.g. ›MS Explorer‹, ›Firefox‹).
Webbrowser is open.
›Java Runtime Environment‹ is installed.
Enter the IP address of the x/e-touchPANEL in the address field and confirm with the Enter key
-> The x/e-touchPANEL appears in the browser and can be operated and configured using the mouse pointer
and keyboard.
-> In addition, the links get last test, get complete testbook and more... are displayed, see "
".Uploading/downloading files and test protocols, p. 103
I NOTICE
Please refer to the Help menu or to your operating system's manual on how to assign a permanent IP address.
The previous chapter explains how to set the IP address in the x/e-touchPANEL, see "Setting an IP address on
".the x/e-touchPANEL, p. 100
I NOTICE
For PCs / laptops with Firewall or other protection software, please contact your IT specialist.
