6.6.3. Configuring buttons in the Home menu
The following table lists the optional configurations of the buttons depending on the Application. The Dim buttons
can only be configured in the Basic Application. It is only possible to dim the white light (groups A to D) in the
ColourApplication.
Button / Option in the Basic Application Button / Option in the Colour Application
Scene Scene
- Zone
- Colour scene
OFF (on Clean page) OFF (on Clean page)
ON (on Clean page) ON(on Clean page)
No function_
Default (factory setting)_
Special: _
SDL1 to SDL6_
SQ1 to SQ6_
Schedule list_
Stop_
No function_
Default (factory setting)_
Special:_
SDL1 to SDL6_
SQ1 to SQ6_
Schedule list_
Stop_
1 colour for 1 to 4 zones_
4 zones (1 colour for each zone)_
No function_
Broadcast OFF (switch off all operating devices)_
Group OFF_
G1 to G16_
No function_
Broadcast OFF (switch off all operating devices)_
Zone OFF_
Zone 1 to 4_
No function_
Broadcast 100% (switch on all operating devices)_
Group 100%_
G1 to G16_
No function_
Broadcast 100% (switch on all operating devices)_
Zone 100%_
Zone 1 to 4_
