User's Manual
750 50 0045 03 12
4. Use the setting gauge supplied with the
instrument to carry out this operation.
Note:
A different setting gauge may be used. In this
case, its dimension must be configured in the set-
up menu (§ 9).
5. Move the measuring insert downwards (use the
handwheel for the displacement of the measuring
carriage) until it touches the surface and an
acoustic signal confirms the measurement
(=probing).
6. Without moving any part (instrument and gauge),
move the measuring insert towards the top and
perform the same sequence on the upper surface
of the setting gauge.
7. Repeat the sequences 5 and 6 one more time.
This allows establishing the probe constant more
precisely.
2x
8. The screen will display the setting gauge value
during the latest probing, as well as that of the
new probe constant. The instrument is then ready
to be used.
In motorized mode (V5 & V6) this procedure can be
automatically carried out by pressing the key opposite
The probe constant needs to be checked and stored again after each measuring
insert change, after change of its position in the holder, after each adjustment of
the measuring force or adjustment of the floating probe suspension.
