13. TECHNICAL SPECIFICATIONS
V3 400 700
Measuring range mm (in)
407 (16)
711 (28)
Application range mm (in)
508 (20)
812 (32)
Max. permissible errors, B
MPE
µm
7
8
Repeatability, R
MPE
µm
2 (Ø: 4)
Perpendicularity deviation (frontal), S
MPE
µm
10
15
Max. resolution mm (in)
0.001 (0.00005)
Measuring force N
0.75 ÷ 1.5
Autonomy h
40
Data output
USB / RS232
Air cushion
No
Protection grade of measuring system (CEI 60529)
IP67
Weight kg
21
24
Max. weight of measuring insert & holder g
400
Max. manual displacement speed mm/s
1000
Operational temperature °C
+10 ÷ +40
Storage temperature °C
-10 ÷ +40
Relative humidity (operation and storage) HR
5 ÷ 75 % (without condensation)
V4 400 700
Measuring range mm (in)
407 (16)
711 (28)
Application range mm (in)
719 (28)
1023 (40)
Max. permissible errors, B
MPE
µm
4.5
6
Repeatability, R
MPE
µm
2 (Ø: 4)
Perpendicularity deviation (frontal), S
MPE
µm
10
15
Max. resolution mm (in)
0.001 (0.00005)
Measuring force N
0.75 ÷ 1.5
Autonomy h
20
Data output
USB / RS232
Air cushion
Yes
Protection grade of measuring system (CEI 60529)
IP67
Weight kg
21
24
Max. weight of measuring insert & holder g
400
Max. manual displacement speed mm/s
1000
Operational temperature °C
+10 ÷ +40
Storage temperature °C
-10 ÷ +40
Relative humidity (operation and storage) HR
5 ÷ 75 % (without condensation)
