Samba
17
FITTING THE RISER RAIL
Decide the position for the rail on the wall
within the shower area. Proceed as follows:
Offer one of the two brackets to the wall for the
lower position only. Note there are three holes
in the brackets but two screws will usually be
enough. However, the centre hole must be used
so mark this and either of the other two. Drill
and plug the wall. (The wallplugs provided are
suitable for most brick walls – use an appropriate
masonry drill, but if the wall is plasterboard or a
soft building block, you must use suitable wallplugs
and a suitable drill bit).
Replace the bracket to the wall and secure to
the wall with the screws supplied (fig.24).
Locate the rail onto this lower bracket, checking
that the rail engages fully on the bracket. Make
sure the indent in the riser rail engages into the
cut-out on the bracket end (fig.25).
Locate the second bracket on top of the rail.
Align the rail vertically, then mark the centre
hole and one of the other two holes. Remove
the bracket and rail. Drill and plug the wall.
Push the sprayhead holder into the saddle and
turn to secure (fig.26). Make sure that the
narrow end faces down. Fit the lever into the
saddle and turn so that the thumb lever is facing
towards you (fig.27).
Slide the assembly onto the rail (fig.28).
Tighten to the rail by pushing the lever away
from you. When tight, the lever should be
facing upwards. If not, slacken off and remove
from the rail. Rotate the lever 180° within the
slider/holder assembly then replace onto the rail
and tighten. Make sure the narrow end of the
sprayhead holder is in the lowermost position.
