Samba
ii
CONTENTS Page
Important safety information 1
Introduction 2
Specifications 2
Advice to users 2
Key to main components 3
Electrical requirements 4 − 5
Water requirements 6
Siting of the shower 7
Fitting the shower to the wall 8 − 9
Plumbing connections 10
Electrical connections 11
Replacing the cover 12
Commissioning 13
Operating the shower 14 − 15
Operating functions 16
Fitting the riser rail 17 − 18
Fitting the hose and sprayhead 18
Cleaning 19
Instructions for installers and service
engineers only
20
Spare parts 21 − 22
Fault finding 23 − 24
Guarantee, service policy, etc. rear cover
To check the product suitability for commercial and multiple installations, please contact
Triton’s specification advisory service before installation.
Telephone: +44 (0) 24 7632 5491
Facsimile: +44 (0) 24 7632 4564
E mail: technical@triton.plc.uk
