REPLACING THE COVER
Position the power selector on the cover to the
ECONOMY position (fig.14).
Make sure the power selector spindle is aligned with
the screw at the 6 o'clock position as shown in fig.15.
To make sure that the temperature control is correctly
positioned on the stabilising valve, temporarily place
the cover in position so that the splines engage and
rotate the temperature control fully clockwise until a
‘stop’ is felt (fig.15).
Fig.15
Fig.14
Economy
position
Power
selector
The valve is now in the closed position.
Remove the cover and position the temperature
control so that it points towards the STOP position
(fig.16).
Replace the cover squarely to the backplate and guide into
position so that the knobs locate correctly into the spindle.
Should any difficulty arise, recheck the points above.
Secure the cover in position with the two retaining
screws.
DO NOT switch on the electricity supply to
the shower until the commissioning has
been carried out.
T
u
r
n
c
l
o
c
k
w
i
s
e
u
n
t
i
l
a
s
t
o
p
i
s
f
e
l
t
Temperature
control
Fig.16
WARNING!
The PRD tube MUST be
positioned correctly
when fitting the cover.
Failure to do so may
damage the unit if
the PRD operates and
will invalidate product
warranty and approvals.
Cover
PRD
Tube
