11
T60X
FITTING THE SHOWER TO THE WALL
WARNING!
Check there are no hidden cables or
pipes before drilling holes for wall
plugs. Use great care when using
power tools near water. The use of
a residual current device (RCD) is
recommended.
Unscrew the top and bottom retaining screws
(fig.6) and lift the cover from the backplate.
NOTE: The control knobs are an integral part of
the cover — do not attempt to remove them.
Entry positions for the mains water and electrical
supplies are at the top, bottom, or at the rear of
the unit.
If a bottom entry has been chosen, fit the
appropriate cut-out in the top of the backplate
(fig.7).
If a top entry has been chosen, fit the appropriate
cut-out in the bottom of the backplate (fig.8).
Fig.8
Fig.7
Fig.6
