4
T60X
This book contains all the necessary fitting and
operating instructions for your electric shower.
Please read them carefully.
The shower installation must be carried out by a
suitably qualified person and in the sequence of this
instruction book.
Care taken during the installation will guarantee
a long, trouble-free life from your shower.
SPECIFICATIONS
Electrical
Nominal power Nominal power
rating at 240V rating at 230V
8.5kW – (40A MCB rating) 7.9kW – (40A MCB rating)
9.5kW – (40A MCB rating) 8.7kW – (40A MCB rating)
10.5kW – (45A MCB rating) 9.6kW – (40A MCB rating)
Water
Inlet connection – 15mm diameter.
Outlet connection – ½” BSP male thread.
Entry Points
Water – Right: top, back bottom, bottom.
Cable – Right: top, middle back, bottom.
Materials
Backplate, cover, controls, shower head – ABS.
Sprayplate – Acetal.
Elements – Minerally insulated corrosion resistant
metal sheathing.
Dimensions
Height – 230mm
Width – 217mm
Depth – 103mm
Standards and Approvals
Splashproof rating IPX4.
Complies with the requirements of current British
and European safety standards for household and
similar electrical appliances.
Complies with requirements of the British
Electrotechnical Approvals Board (BEAB).
Meets with Compliance with European
Community Directives (CE) and UK Community
Directives (UKCA).
.
ADVICE TO USERS
The following points will help you understand
how the shower operates:
a. The electric heating elements operate at a
constant rate at your chosen power setting.
It is the rate of the water passing through
the heater can which determines the water
temperature. The slower the flow the hotter
the water becomes, and the faster the flow
the cooler the water.
b. During winter, the mains water supply will be
cooler than in summer, so the temperature
of the shower will vary between seasons on
any one setting of the temperature control.
At different times of the year you may have to
adjust the position of the temperature control
to maintain your desired temperature setting.
c. The stabiliser valve minimises variations in
shower temperature during mains water
pressure changes. If changes in shower
temperature are experienced during normal
use, it will most likely caused by the water
pressure falling near to or below the minimum
level. The drop in pressure may be due to
water being drawn off at other points in the
house while the shower is in use. If pressure
drops appreciably below the minimum, the
heating elements will automatically cut out.
If ever the water becomes too hot and you
cannot obtain cooler water, first check
that the sprayplate in the shower head has
not become blocked.
DO NOT place items such as soap or shampoo
bottles on top of the unit. Liquid could seep
through the joint between the cover and
backplate, and possibly damage the sealing
rubber.
