Triton T60X User Manual

6
T60X
MAIN COMPONENTS
1. Top pipe/cable entry
2. Bottom pipe/cable entry
3. Area for rear pipe and cable entry
4. Water inlet
5. Wall screw fixings
6. Cover screw fixings
7. Terminal block
8. Power selector assembly
9. Stabilising valve
10. Can and element assembly
11. Thermal cut-out
12. Pressure relief device – PRD
13. Shower outlet
NOTE: Not all wiring is shown for reasons of clarity
40 mm
217 mm
230 mm
Fig.1
1
2
4
5
6
12
8
7
10
11
9
13
3
5
6
5
