Triton T60X User Manual

9
T60X
WATER REQUIREMENTS
The installation must be in accordance with
Water Regulations/Bylaws.
To guarantee activating the heating elements,
the shower must be connected to a mains water
supply with a minimum running pressure of
100kPa (1.0 bar) at a minimum flow rate of eight
litres per minute, and a maximum static pressure
of 1 000kPa (10 bar) for 8.5 and 9.5Kw.
10.5Kw requires 150kPa (1.5 bar) at a minimum
flow rate of eleven litres per minute, and a
maximum static pressure of 1 000kPa (10 bar).
NOTE: If the stated flow rates are not available,
it may not be possible to achieve optimum
performance from the unit throughout the year.
During periods of high ambient temperatures it
may be necessary to select a low power setting
to achieve your preferred shower temperature.
If it is intended to operate the shower at
pressures above the maximum or below the
minimum stated, contact Customer Experience
for advice.
Fig.4 shows a typical system layout.
DO NOT use jointing compounds on any pipe
fittings for the installation.
Isolating
stopvalve
Mains
water
supply
Shower
unit
Mains electric supply (via double pole switch)
Double
pole
isolating
switch
Separate permanently
connected supply
from consumer unit
Fig.4
*Diagrammatic view – not to scale.
For illustration purposes only.
