Triumph Speed Triple R User Manual

105
Maintenance and Adjustment
The spring pre-load adjusters are located at
the top of each fork.
To change the spring pre-load, rotate the
adjuster clockwise to increase pre-load, or
counter-clockwise to decrease pre-load.
Always count the number of clockwise turns
from the fully counter-clockwise position and
set both forks to the same settings.
Note:
• For Speed Triple and Speed
_Triple_r the motorcycle is
delivered from the factory with
the spring pre-load set at 7
clockwise turns from the fully anti-
clockwise position.
Rebound Damping Adjustment
Speed Triple
1. Rebound damping adjuster
The rebound damping adjuster is located at
the top of each fork.
To change the rebound damping force, rotate
the slotted adjuster clockwise to increase, or
counter-clockwise to decrease. Always count
the number of counter-clockwise turns from
the fully clockwise position and set both forks
to the same settings.
Note:
• The motorcycle is delivered from
the factory with the rebound set at
1.5 counter-clockwise turns from
the fully clockwise position.
1
cgfj_2

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
