Triumph Speed Triple R User Manual

36
General Information
Coolant Temperature Gauge
1. Coolant temperature gauge
The coolant temperature gauge indicates the
temperature of the engine coolant.
When the ignition is switched on, all 8 bars of
the display will be shown. When the engine is
started from cold the display will show 1 bar.
As the temperature increases more bars will
be shown in the display. When the engine is
started from hot the display will show the
relevant number of bars, dependant on
engine temperature.
The normal temperature range is between 3
and 5 bars.
If the coolant temperature becomes too high
the display will show 8 bars and will start to
flash. The high coolant temperature warning
light in the tachometer will also be
illuminated.
Fuel Gauge
1. Fuel gauge
2. Buttom B
The fuel gauge indicates the amount of fuel
in the tank.
With the ignition switched on, the number of
bars shown in the display indicates the level
of fuel.
When the fuel tank is full all 12 bars are
displayed and when empty, no bars are
displayed. Other gauge markings indicate
intermediate fuel levels between full and
empty.
1
cfik_1
1
2

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
