Triumph Speed Triple R User Manual

43
General Information
Tire Pressure Warning Light
(Only on models fitted with TPMS)
The tire pressure warning light
works in conjunction with the tire
pressure monitoring system (see
page 37).
The warning light will only illuminate when
the front or rear tire pressure is below the
recommended pressure. It will not illuminate
if the tire is over inflated.
When the warning light is illuminated, the
TPMS symbol indicating which is the deflated
tire and its pressure will automatically be
visible in the display area.
1. TPMS symbol
2. Rear tire, identified
3. Tire pressure
The tire pressure at which the warning light
illuminates is temperature compensated to
20°C but the numeric pressure display
associated with it is not (see page 40). Even if
the numeric display seems at or close to the
standard tire pressure when the warning light
is on, a low tire pressure is indicated and a
puncture is the most likely cause.
R
cfio_17
1
2
3
Warning
Stop the motorcycle if the tire pressure
warning light illuminates. Do not ride the
motorcycle until the tires have been
checked and the tire pressures are at their
recommended pressure when cold.

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
