Triumph Speed Triple R User Manual

53
General Information
Whenever the side stand is used before
riding, always ensure that the stand is fully up
after first sitting on the motorcycle.
For instructions on safe parking, refer to the
'How to Ride the Motorcycle' section.
Tool Kit and Handbook
The tool kit and handbook are both located
under the seat.
Seat Lock
1. S e a t l o c k
The seat lock is located on the left hand side
of the motorcycle, on the frame below the
seat. To remove the seat, insert the ignition
key into the seat lock and turn it counter-
clockwise while pressing down on the rear of
the seat. This will release the seat from its lock
and allow it to be slid rearwards for complete
removal from the motorcycle.
Located on the underside of the seat is the
fuel tank support.
1. S e a t
2. Fuel tank support
Seat Care
To prevent damage to the seat or seat cover,
care must be taken not to drop or lean the
seat against any surface which may damage
the seat or seat cover.
See page 12 6 for seat cleaning information.
1
cgex
Caution
To prevent damage to the seat or cover,
care must be taken not to drop the seat.
Do not lean the seat against the motorcycle
or any surface which may damage the seat
or cover. Instead, place the seat, with the
cover facing upwards, on a clean, flat
surface which is covered with a soft cloth.
Do not place any item on the seat which
may cause damage or staining to the seat
cover.
1
cgfp
2

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
