Triumph Speed Triple R User Manual

39
General Information
System Display
1. TPMS symbol
2. Tire pressure display
3. Front tire, identified
4. Rear tire, identified
5. Button A
6. Button B
To access the tire pressure display, turn the
ignition to the ON position.
Press and release button 'A' until psi or bAr is
visible in the display screen.
Press and release button 'B' to select the front
or rear tire pressure.
When the tire pressure monitoring system
has been selected, —— psi or bAr will be
visible in the display screen until the
motorcycle is travelling at a speed greater
than 12 mph (20 km) and the tire pressure
signal is received.
To exit the tire pressure display, press and
release button 'A' to the desired display.
Sensor Batteries
When the battery voltage in a pressure
sensor is low, LO bAt will be displayed and
the TPMS symbol will indicate which wheel
sensor has the low battery voltage. If the
batteries are completely flat, only dashes will
be visible in the display screen, the red TPMS
warning light will be on and the TPMS
symbol will flash continuously. Contact your
authorized Triumph dealer to have the sensor
replaced and the new serial number
recorded in the spaces provided on page 38.
1. TPMS symbol
2. Display screen
3. Front tire, identified
4. Rear tire, identified
5. TPMS warning light
With the ignition switch turned to the ON
position, if the TPMS symbol flashes
continuously and the TPMS warning light
remains on there is a fault with the TPMS
Warning
Do not attempt to switch between front
and rear tire display modes with the
motorcycle in motion as this may lead to
loss of motorcycle control and an accident.
F
R
cfio_14
1
2
3
4
5
6
chdo_6
4
5
1
3
2

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
