Triumph Speed Triple R User Manual

31
General Information
When the gearshift light mode has been
selected, the tachometer needle will move
round to the last set position. The rpm will be
shown in the display screen with the 1,000
units flashing.
1. RPM 1,000 units
2. Button A
3. Button B
Changing the Set Speed
To change the setting in increments of
1,000 rpm, press button 'A'. Each individual
press of button 'A' will then increase the
setting in increments of 1,000 rpm, up to the
maximum rpm limit. When the maximum
rpm limit is reached, the setting will return to
3,500 rpm.
Note:
• If the rpm 1000 units is set to the
maximum rpm limit, SHIFt will be
shown.
When the correct setting is shown press
button 'B' and the rpm 100 units start
flashing.
1. R P M 10 0 u n i t s
2. Button A
3. Button B
The setting can now be changed in
increments of 100 rpm, again up to the
maximum rpm limit.
Note:
• In this mode, when 900 is reached,
the next press of button 'A' will
reset the display to 000.
Each individual press of button 'A' will
increase the setting in increments of 100 rpm.
When the correct setting is shown, pressing
button 'B' will confirm the setting, SHift will
be visible in the display screen and all the
gearshift lights will flash.
Press and release button 'A' until r
Eturn is
visible in the display screen then press
button 'B'. Trip 1 will be visible in the display
screen.
chdo_3
1
3
2
chdo_3
1
3
2

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
