Maintenance and Adjustment
Fuel Tank
Raising
Remove the seat (see page 53) and remove
the fuel tank prop from its location on the
seat base. Store the seat as described on
page 53.
1. S e a t
2. Fuel tank prop
Release the three fasteners and remove the
front panel from the fuel tank.
1. Front panel
2. Fasteners
Remove the front fasteners from the fuel
tank.
1. Fasteners
2. Fuel tank
Pivot the fuel tank upwards at the front.
While holding the fuel tank in the raised
position, locate the fuel tank prop into the
support points on the air box and the fuel
tank.
1
cgfp_1
2
cgfo
2
1
22
cgff
2
1

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
