Triumph Speed Triple R User Manual

46
General Information
Brake and Clutch Lever
Adjusters
An adjuster is fitted to both the front brake
and clutch levers. The adjusters allow the
distance from the handlebar to the levers to
be changed to suit the span of the operator's
hands.
Clutch Lever
1. Clutch ever
2. Adjuster wheel
3. Triangular mark
To adjust the clutch lever, push the lever
forward and turn the adjuster wheel to align
one of the numbered positions with the
triangular mark on the lever holder.
The distance from the handlebar grip to the
released lever is shortest when set to number
four and longest when set to number one.
Brake Lever
1. Brake lever
2. Adjusting screw
To adjust the brake lever, push the lever
forward and turn the adjusting screw in to
increase the distance or out to shorten the
distance from the handlebar.
1
3
2
4
1
2
cggr_1
3
Warning
Do not attempt to adjust the levers with the
motorcycle in motion as this may lead to
loss of motorcycle control and an accident.
After adjusting the levers, operate the
motorcycle in an area free from traffic to
gain familiarity with the new lever setting.
Do not loan your motorcycle to anyone as
they may change the lever setting from the
one you are familiar with causing loss of
control or an accident.
cggq
1
2

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
