Triumph Speed Triple R User Manual

108
Maintenance and Adjustment
Pseed Triple R
1. Rebound damping adjuster
The rebound damping adjuster is accessible
from the left hand side of the motorcycle. It is
coloured black and is situated close to the
rear suspension reservoir.
To adjust the rebound damping setting, rote
the adjuster clockwise to increase rebound
damping and anti-clockwise to decrease.
Always count the number of clicks anti-
clockwise from the fully clockwise position
noting that the first stop (click position) is
counted as zero.
Note:
• The motorcycle is delivered from
the factory with the rebound
adjuster set at 10 clicks from the
fully clockwise position.
Compression Damping Adjustment
Speed Triple
1. Compression damping adjuster
The compression damping adjuster is
accessible from the left hand side of the
motorcycle. It is situated below the rear
suspension unit reservoir.
To adjust the compression damping setting,
rotate the slotted adjuster clockwise to
increase, or counter-clockwise to decrease.
Always count the number of counter-
clockwise turns from the fully clockwise
position.
Note:
• The motorcycle is delivered from
the factory with the compression
damping set at 1.0 counter-
clockwise turns from the fully
clockwise position.
1
chcx
1
cgfb

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
