Triumph Speed Triple R User Manual

35
General Information
When the data retrieval mode is accessed, the
lap time for the first lap will be displayed. The
lap number will be displayed in the
speedometer display position.
1. Lap number
2. Stop watch icon
3. Lap timer
4. Button A
5. Button B
Press and release button 'A' until the desired
lap (up to a maximum of 50 laps) is
displayed.
Press and release button 'B' to scroll through
the data available in the following order:
• Average Speed (per lap or total of all
laps)
• Maximum Speed (per lap or
maximum speed achieved)
• Distance Travelled (per lap or total of
all laps)
•Lap Time
1. Lap number
2. Stop watch icon
3. Data Retrieval Mode (average speed
shown
4. Button A
5. Button B
The speed and distance will be displayed in
kilometres or miles, according to the units
displayed by the speedometer.
Lap Timer Reset and Exit
To reset the lap timer and exit lap timer, press
button 'B' for 2 seconds. After 2 seconds, the
lap timer will reset and Lap will be shown in
the display screen. This will delete the stored
data for all stored laps.
To exit the data retrieval mode without
resetting the lap timer, press button 'A' for
2 second, Lap will be visible in the display
screen. Press and release button 'A' to the
desired display.
1
cfiv_12
3
2
5
4
cfiw_11
1
4
5
2
3

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
