Triumph Speed Triple R User Manual

15
Parts Identification
PARTS IDENTIFICATION
16.Muffler
17. Tool kit
18.Rear brake fluid reservoir
19.Battery
20.Front fork
21. Rear brake disc
22.Rear brake caliper
23.Rear suspension unit
24.Rear brake pedal
25.Oil filler cap/Dipstick
26.Clutch cable
chcv_2
17 18 19 20
23 24 25 2621 22
16

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
